Layout method of sub-control module of range extender for Auto-Rickshaw

2025-09-29 15:36:34

There are many layout methods for sub-control module of range extender for Passenger Auto-Rickshaw. Commonly used layout methods include proximity principle method, indoor small space method and modular design method.

These layout methods have their own advantages and disadvantages. Among them, the principle of proximity layout can reduce the length of vehicle wiring harness and radon gas pipeline

Layout method of range extender for Zonglong Auto-Rickshaw: start from the installation structure of range extender for Auto-Rickshaw.

The software structure of range extender system for Auto-Rickshaw is changed to a quick-replaceable structure. In view of the problem of insufficient driving capacity of pure electric vehicles, the range extender system software is adopted.

The principle is: according to the front conical positioning assembly, rear clamping positioning pin, lock buckle and side auxiliary partition, all range extenders of Zonglong Auto-Rickshaw are quickly positioned.

When gradually installed, the movable pulley of the bottom plate contacts the slide rail, and after the end is lifted, the movable pulley slides into the slide rail. At this time, it relies on the slide rail to support the point.
